10600 nm | ZnSE
Our economical CO2 F-Theta lenses for the wavelength of 10,600 nm, are made of high-quality zinc selenide (ZnSe). Models are available for different working areas and beam diameters.
They are typically used in the field of cost-efficient, laser-based marking and coding.
Special Features:
Mechanical mount, easy integration
Working areas up to 410 x 410 mm
Focal lengths f-70 to f-600
Strong price-performance ratio
Typical Laser Applications:
Marking
Engraving
Cutting
Typical Materials:
plastics
Foils & Labels
Lacquer
wood
Paper / Cardboard
and more
10600 nm | ZnSE
| Model Name | Wavelength | Nominal Focal Length | Working Distance | Maximum Scan Field | Maximum Input Beam Diameter | Minimum Spot Size | Lens Material | Mounting Thread | Lens Diameter | Cooling Method | Inquiry | Detail |
|---|---|---|---|---|---|---|---|---|---|---|---|---|
| f-70-10-10.6 | 10600 nm | 70 mm | 57.130 mm | 50 mm x 50 mm | 10 mm | 135.79 μm | ZnSe | M85x1 | 90 mm | Air | ||
| f-100G-10-10.6 | 10600 nm | 100 mm | 85.500 mm | 70 mm x 70 mm | 10 mm | 193.98 μm | ZnSe | M85x1 | 90 mm | Air | ||
| f-100K-10-10.6 | 10600 nm | 100 mm | 112.844 mm | 60 mm x 60 mm | 10 mm | 193.98 μm | ZnSe | M85x1 | 90 mm | Air | ||
| f-150-12-10.6 | 10600 nm | 150 mm | 131.500 mm | 110 mm x 110 mm | 12 mm | 242.48 μm | ZnSe | M85x1 | 90 mm | Air | ||
| f-200-15-10.6 | 10600 nm | 200 mm | 185.727 mm | 100 mm x 100 mm | 15 mm | 258.64 μm | ZnSe | M85x1 | 90 mm | Air | ||
| f-220-14-10.6 | 10600 nm | 220 mm | 242.294 mm | 140 mm x 140 mm | 14 mm | 304.8 μm | ZnSe | M85x1 | 90 mm | Air | ||
| f-250-15-10.6 | 10600 nm | 250 mm | 244.600 mm | 175 mm x 175 mm | 15 mm | 323.3 μm | ZnSe | M85x1 | 90 mm | Air | ||
| f-250-20-10.6 | 10600 nm | 250 mm | 242.800 mm | 175 mm x 175 mm | 20 mm | 159.4 μm | ZnSe | M85x1 | 90 mm | Air | ||
| f-275-20-10.6 | 10600 nm | 275 mm | 309.970 mm | 150 mm x 150 mm | 20 mm | 156.81 μm | ZnSe | M85x1 | 90 mm | Air | ||
| f-300-12-10.6 | 10600 nm | 300 mm | 298.800 mm | 210 mm x 210 mm | 12 mm | 484.95 μm | ZnSe | M85x1 | 90 mm | Air | ||
| f-300-14-10.6 | 10600 nm | 300 mm | 295.055 mm | 210 mm x 210 mm | 14 mm | 415.7 μm | ZnSe | M85x1 | 90 mm | Air | ||
| f-300-30-10.6 | 10600 nm | 300 mm | 348.800 mm | 200 mm x 200 mm | 30 mm | 114.6 μm | ZnSe | M102x1 | 120 mm | Air | ||
| f-430-15-10.6 | 10600 nm | 430 mm | 420.200 mm | 300 mm x 300 mm | 15 mm | 556.08 μm | ZnSe | M85x1 | 90 mm | Air | ||
| f-480-20-10.6 | 10600 nm | 480 mm | 467.700 mm | 350 mm x 350 mm | 20 mm | 466.52 μm | ZnSe | M85x1 | 90 mm | Air | ||
| f-500-20-10.6 | 10600 nm | 500 mm | 552.515 mm | 350 mm x 350 mm | 20 mm | 484.95 μm | ZnSe | M85x1 | 120 mm | Air | ||
| f-580-20-10.6 | 10600 nm | 580 mm | 663.809 mm | 400 mm x 400 mm | 20 mm | 562.5 μm | ZnSe | M85x1 | 120 mm | Air | ||
| f-600-30-10.6 | 10600 nm | 600 mm | 656.387 mm | 410 mm x 410 mm | 30 mm | 350 μm | ZnSe | M85x1 | 120 mm | Air | ||
| f-720-14-10.6 | 10600 nm | 720 mm | 706.737 mm | 520 mm x 520 mm | 14 mm | 872 μm | ZnSe | M85x1 | 90 mm | Air | ||
| f-930-14-10.6 | 10600 nm | 930 mm | 919.750 mm | 700 mm x 700 mm | 14 mm | 1,130 μm | ZnSe | M85x1 | 90 mm | Air |
