AOB Series
𝗗𝗶𝘀𝗰𝗼𝘃𝗲𝗿 𝘁𝗵𝗲 𝗔𝗢𝗕 𝗦𝗲𝗿𝗶𝗲𝘀: 𝗣𝗲𝗿𝗳𝗲𝗰𝘁 𝗣𝗼𝘄𝗲𝗿 𝗗𝗶𝘀𝘁𝗿𝗶𝗯𝘂𝘁𝗶𝗼𝗻 𝗳𝗼𝗿 𝗗𝗲𝗺𝗮𝗻𝗱𝗶𝗻𝗴 𝗟𝗮𝘀𝗲𝗿 𝗣𝗿𝗼𝗰𝗲𝘀𝘀𝗲𝘀
Our advanced 𝗔𝗢𝗕 𝗳𝗶𝗯𝗲𝗿 𝗹𝗮𝘀𝗲𝗿 𝗺𝗼𝗱𝗲𝗹𝘀 with a modulable beam profile deliver combined output power – ideal for precise Laser Welding and Laser Cutting.
𝗔𝗱𝘃𝗮𝗻𝘁𝗮𝗴𝗲𝘀 𝗮𝘁 𝗮 𝗚𝗹𝗮𝗻𝗰𝗲:
✅ 𝗢𝗽𝘁𝗶𝗺𝗶𝘇𝗲𝗱 𝗕𝗲𝗮𝗺 𝗣𝗿𝗼𝗳𝗶𝗹𝗲: Each AOB series model features two independent fiber cores. This allows for precise beam profile adjustment by distributing laser power across both cores, perfectly tailored to your specific process requirements.
✅ 𝗪𝗶𝗱𝗲 𝗥𝗮𝗻𝗴𝗲 𝗼𝗳 𝗖𝗼𝗿𝗲 𝗗𝗶𝗮𝗺𝗲𝘁𝗲𝗿𝘀: Various laser models are available with different fiber core diameters. This flexibility ensures that the laser beam properties are precisely matched to your individual application needs.
✅ 𝗦𝗰𝗮𝗹𝗮𝗯𝗹𝗲 𝗣𝗼𝘄𝗲𝗿 𝗢𝗽𝘁𝗶𝗼𝗻𝘀: AOB fiber lasers offer different output power options and allow for project-specific adjustments to the maximum laser power for both fiber cores.
𝗟𝗲𝗮𝗿𝗻 𝗺𝗼𝗿𝗲 about the powerful capabilities of the AOB series and how they can optimize your laser applications.
𝗖𝗼𝗻𝘁𝗮𝗰𝘁 𝘂𝘀 𝘁𝗼𝗱𝗮𝘆 for personalized advice and tailored solutions!
Our advanced 𝗔𝗢𝗕 𝗳𝗶𝗯𝗲𝗿 𝗹𝗮𝘀𝗲𝗿 𝗺𝗼𝗱𝗲𝗹𝘀 with a modulable beam profile deliver combined output power – ideal for precise Laser Welding and Laser Cutting.
𝗔𝗱𝘃𝗮𝗻𝘁𝗮𝗴𝗲𝘀 𝗮𝘁 𝗮 𝗚𝗹𝗮𝗻𝗰𝗲:
✅ 𝗢𝗽𝘁𝗶𝗺𝗶𝘇𝗲𝗱 𝗕𝗲𝗮𝗺 𝗣𝗿𝗼𝗳𝗶𝗹𝗲: Each AOB series model features two independent fiber cores. This allows for precise beam profile adjustment by distributing laser power across both cores, perfectly tailored to your specific process requirements.
✅ 𝗪𝗶𝗱𝗲 𝗥𝗮𝗻𝗴𝗲 𝗼𝗳 𝗖𝗼𝗿𝗲 𝗗𝗶𝗮𝗺𝗲𝘁𝗲𝗿𝘀: Various laser models are available with different fiber core diameters. This flexibility ensures that the laser beam properties are precisely matched to your individual application needs.
✅ 𝗦𝗰𝗮𝗹𝗮𝗯𝗹𝗲 𝗣𝗼𝘄𝗲𝗿 𝗢𝗽𝘁𝗶𝗼𝗻𝘀: AOB fiber lasers offer different output power options and allow for project-specific adjustments to the maximum laser power for both fiber cores.
𝗟𝗲𝗮𝗿𝗻 𝗺𝗼𝗿𝗲 about the powerful capabilities of the AOB series and how they can optimize your laser applications.
𝗖𝗼𝗻𝘁𝗮𝗰𝘁 𝘂𝘀 𝘁𝗼𝗱𝗮𝘆 for personalized advice and tailored solutions!
Special Features:
Programmable beam profile
Combined power up to 6 kW
Double fiber core for power output
Optimized for welding and cutting
Typical Laser Applications:
Welding
Cutting
Typical Materials:
Copper
Stainless Steel
Aluminium
and more
Titanium
AOB Series
| Model Name | Wavelength | Total Average Output Power CW | Central Beam Output Power CW | Annular Beam Output Power CW | Modulation Frequency | Pulse Frequency | Net Weight | Mechanical Dimensions Depth | Mechanical Dimensions Height | Mechanical Dimensions Width | Cooling Method | Inquiry | Detail |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
| AOB-1000/1000-W | 1080 nm | 2,000 W | 1,000 W | 1,000 W | 0 - 5 kHz | 0 - 5 kHz | 205 kg | 674 mm | 762 mm | 1,152 mm | Water | ||
| AOB-2000/2000-W | 1080 nm | 4,000 W | 2,000 W | 2,000 W | 0 - 5 kHz | 0 - 5 kHz | 205 kg | 674 mm | 762 mm | 1,152 mm | Water | ||
| AOB-2000/3000-W | 1080 nm | 5,000 W | 2,000 W | 3,000 W | 0 - 5 kHz | 0 - 5 kHz | 250 kg | 674 mm | 762 mm | 1,152 mm | Water | ||
| AOB-3000/3000-W | 1080 nm | 6,000 W | 3,000 W | 3,000 W | 0 - 5 kHz | 0 - 5 kHz | 290 kg | 674 mm | 762 mm | 1,152 mm | Water | ||
| AOB-4000/2000-W | 1080 nm | 6,000 W | 4,000 W | 2,000 W | 0 - 5 kHz | 0 - 5 kHz | 380 kg | 863 mm | 866 mm | 1,310 mm | Water |
