CW-Laser | Singlemode
CW lasers with single-mode fiber, for output powers up to 3 kW.
Due to high power stability and excellent optical characteristics, they are ideal for use in additive manufacturing, as well as for precise laser cutting and welding.
Their compact and robust design, in 19-inch format, enables easy integration. All models offer a high level of efficiency combined with very low maintenance and a long lifetime. This makes their use extremely economical.
Our CW laser sources can be easily adapted to your application requirements.
Different fiber core diameters, fiber lengths and optical outputs are available for application-specific adaptation. Designed for high speed and precise results.
Special Features:
Single-mode up to 3000 Watt
Compact industrial design
Fiber cores of 14 µm, 20 µm, 25 µm
Outstanding price-performance ratio
Typical Laser Applications:
Cutting
Structuring
Welding
Additive Manufacturing
Typical Materials:
Stainless Steel
Aluminium
Titanium
Ceramics
Plastics
and more
CW-Laser | Singlemode
| Model Name | Wavelength | Nominal Output Power CW | Beam Quality | Beam Parameter Product (BPP) | Modulation Frequency | Net Weight | Mechanical Dimensions Depth | Mechanical Dimensions Height | Mechanical Dimensions Width | Cooling Method | Inquiry | Detail |
|---|---|---|---|---|---|---|---|---|---|---|---|---|
| CW-500SM-L | 1080 nm | 510 W | 1.3 <M² | 0.45 mm*mrad | 1 - 20 kHz | 23 kg | 575 mm | 105 mm | 482 mm | Water | ||
| CW-1000SM-L | 1080 nm | 1,020 W | 1.3 <M² | 0.45 mm*mrad | 1 - 20 kHz | 25 kg | 575 mm | 105 mm | 482 mm | Water | ||
| CW-1000SM-L-PLD | 1080 nm | 1,020 W | 1.3 <M² / 1.5 <M² | 0.45 mm*mrad / 0.6 mm*mrad | 1 Hz - 20 kHz | 30 kg | 571 mm | 135 mm | 482 mm | Water | ||
| CW-1500SM-L | 1080 nm | 1,530 W | 1.3 <M² | 0.45 mm*mrad | 1 - 20 kHz | 27 kg | 575 mm | 105 mm | 482 mm | Water | ||
| CW-1500SM-L-PLD | 1080 nm | 1,530 W | 1.3 <M² / 1.5 <M² | 0.45 mm*mrad / 0.6 mm*mrad | 1 Hz - 20 kHz | 32 kg | 571 mm | 135 mm | 482 mm | Water | ||
| CW-2000SM-L | 1080 nm | 2,050 W | 1.3 <M² | 0.45 mm*mrad | 1 - 20 kHz | 31 kg | 575 mm | 105 mm | 482 mm | Water | ||
| CW-2000SM-L-PLD | 1080 nm | 2,050 W | 1.3 <M² / 1.5 <M² | 0.45 mm*mrad / 0.6 mm*mrad | 1 Hz - 20 kHz | 36 kg | 571 mm | 135 mm | 482 mm | Water | ||
| CW-3000SM-L | 1080 nm | 3,000 W | 1.5 <M² | 0.6 mm*mrad | 1 - 20 kHz | 41 kg | 742 mm | 105 mm | 482 mm | Water | ||
| CW-3000SM-L-PLD | 1080 nm | 3,050 W | 1.5 <M² | 0.6 mm*mrad | 1 Hz - 20 kHz | 46 kg | 78 mm | 135 mm | 482 mm | Water | ||
| CW-4000SM-L-PLD | 1080 nm | 4,050 W | 1.5 <M² | 0.6 mm*mrad | 1 Hz - 20 kHz | 48 kg | 738 mm | 135 mm | 482 mm | Water |
