PSH-2D-Series
The premium 2-axis scan heads of the PSH-2D-Series, with input apertures from 10 to 30 mm, are characterised by high dynamics and outstanding precision. They enable ultra-precise deflection and positioning of laser beams in the working area.
All models achieve their outstanding precision and long-term stability with exceptionally low drift, through the use of galvanometer motors, which were originally developed for communication by laser in aerospace and therefore also meet the highest industrial requirements.
The models of the PSH-2D series are versatile and have been specially designed for laser applications with very high demands on accuracy and long-term stability. Mirror coatings for wavelengths from 355 to 1080 nm and high laser powers up to 8 kW (CW / 1064 nm) are available.
Application-specific tunings:
Tuning of the deflection units can be tailored to customer-specific applications and enable, for example, an increase in speed or positioning accuracy.
All models achieve their outstanding precision and long-term stability with exceptionally low drift, through the use of galvanometer motors, which were originally developed for communication by laser in aerospace and therefore also meet the highest industrial requirements.
The models of the PSH-2D series are versatile and have been specially designed for laser applications with very high demands on accuracy and long-term stability. Mirror coatings for wavelengths from 355 to 1080 nm and high laser powers up to 8 kW (CW / 1064 nm) are available.
Application-specific tunings:
Tuning of the deflection units can be tailored to customer-specific applications and enable, for example, an increase in speed or positioning accuracy.
Special Features:
Premium 2-axis laser scan heads
Outstanding precision, minimal drift
Laser powers up to 8000 Watt, CW 1064 nm
Designed for challenging laser applications
Typical Laser Applications:
Welding
Additive Manufacturing
Engraving
Cutting
Trimming
Structuring
Drilling
Marking
Typical Materials:
Stainless Steel
Titanium
Aluminium
Copper
silicon
plastics
gold
diamond
technical glass
ceramics
and more
PSH-2D-Series
| Model Name | Wavelength | Maximum Input Beam Diameter | Marking Speed | Writing Speed | Positioning Speed (<) | Net Weight | Mechanical Dimensions Depth | Mechanical Dimensions Height | Mechanical Dimensions Width | Max. Laser Power @ 1064 nm CW (<) | Cooling Method | Inquiry | Detail |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
| PSH-10 | 355 nm / 532 nm / 1064 nm / 10600 nm | 10 mm | 3 m/s | 950 cps | 20 m/s | 2.8 kg | 150 mm | 110 mm | 99 mm | 300 W | Passive | ||
| PSH-14 | 355 nm / 532 nm / 1030 - 1080 nm / 10600 nm | 14 mm | 3 m/s | 770 cps | 15 m/s | 3.2 kg | 156 mm | 119.5 mm | 107.5 mm | 500 W | Passive | ||
| PSH-20 | 1030 - 1080 nm / 10600 nm | 20 mm | 2 m/s | 450 cps | 10 m/s | 5.3 kg | 176 mm | 131 mm | 120 mm | 1,000 W | Passive / Water | ||
| PSH-20-H-W | 1030 - 1080 nm | 20 mm | 2 m/s | 450 cps | 9 m/s | 6.1 kg | 195 mm | 155 mm | 134 mm | 2,000 W | Water | ||
| PSH-30 | 1030 - 1080 nm / 10600 nm | 30 mm | 1 m/s | 200 cps | 7 m/s | 6.7 kg | 206.9 mm | 180 mm | 152 mm | 3,000 W | Water / Passive | ||
| PSH-30-H-3.0-WA | 1030 - 1080 nm | 30 mm | 1 m/s | 260 cps | 5 m/s | 8 kg | 218.5 mm | 165 mm | 180 mm | 8,000 W | Water and Air Flush | ||
| PSH-30-M-W | 1030 - 1080 nm / 1064 nm / 10600 nm | 30 mm | 1 m/s | 280 cps | 9 m/s | 6.6 kg | 206.9 mm | 180 mm | 152 mm | 3,000 W | Water |
